Type

A4 Monochrome Multifunctional Device (Reader/Printer Desktop)

Copy/Print Speed

A4

iR2206: 22 ppm
iR2006N: 20 ppm
iR2206N: 22 ppm

A3

iR2206: 11 ppm
iR2006N: 10 ppm
iR2206N: 11 ppm

Warm-Up Time
(Time from device power on, until copy ready)

13 secs or less

Recovery from sleep mode

4.3 secs

First Copy Time (A4)

7.4 secs

Memory

iR2206: 256 MB
iR2006N & iR2206N: 512 MB

Dimensions (W x D x H)

iR2206: 622 x 589 x 499 mm
iR2006N & iR2206N: 622 x 606 x 600 mm (with ADF)

Weight

iR2206: Approximately 28.7 kg
iR2006N & iR2206N: Approximately 35.5 kg (with ADF)

Installation Space (W × D)

920 x 589 mm (when multi purpose tray is extended)

Power Supply

iR2206: 220 to 240 V AC, 50/60 Hz, 2.4 A
iR2006N & iR2206N: 220 to 240 V AC, 50/60 Hz, 2.7 A

Max Power Consumption

Maximum Power Consumption:

1.5 kWh

When the machine is in the Sleep mode:

2 W

Toner Yield (A4, 6% coverage)

Approx 10,200 sheets (A4, 6% coverage)

Drum Yield

iR2206: Approx 66,000 sheets
iR2006N: Approx 63,700 sheets
iR2206N: Approx 66,000 sheets

Print Resolution

600 x 600 dpi

Page Description Language(s)

iR2206: UFRII LT (Standard)
iR2006N & iR2206N: UFRII LT (Standard), PCL6 (Optional)

Print OS Compatibility

Windows 10/8.1/7, Windows Server 2008/2008 R2/2012/2012 R2/ 2016,
Mac OS X 10.9.5 or later

Interface

Network

iR2206: N/A

iR2006N & iR2206N: Ethernet 100Base-Tx/10Base-T (IEEE 802.3 compliant), WLAN IEEE 802.11b/g/n

Others (Local Print/Scan)

USB2.0 x 1

Network Protocol

iR2206: N/A

iR2006N & iR2206N:
TCP/IP (IPv4/IPv6), USB
Frame type: Ethernet II
Print applications: LPD/Raw/IPP/IPPS/WSD/Mopria /Google Cloud Print/AirPrint/Windows10 Mobile Print

Copy Resolution

600 x 600 dpi

Multiple Copies/Prints

Up to 999 copies

Magnification

25% -400% (1% increment)

Destination

iR2206: N/A
iR2006N & iR2206N: Scan to Email (SMTP), network folders (SMB)

Scan Speed (Simplex, A4, 200dpi)

iR2206: N/A
iR2006N & iR2206N:
BW: 13 sheets/minute
CL: 6 sheets/minute

Address Book

iR2206: N/A
iR2006N & iR2206N: LDAP (5)/Local(104) /One-touch(4)

SEND Resolution

iR2206: N/A
iR2006N & iR2206N: BW/CL 300 x 300 dpi

SEND File Format

iR2206: N/A
iR2006N & iR2206N: PDF/Compact PDF/JPEG/ TIFF

Destination

MF Scan Utility, application compatible with TWAIN/WIA

Supported Protocol

TCP/IP, USB

Scan Speed (Platen, A4, 600 dpi)

BW: 1.71 secs
CL: 3.42 secs

Scan Speed (Simplex, A4, 300 dpi)

BW: 23 sheets/minute
CL: 12 sheets/minute

Scan Resolution

BW: 600 x 600 dpi
CL: 300 x 600 dpi

Scan File Format

TIFF/JPEG/PNG/PDF(Compact, Searchable)/PDF(Divided into Single-Page Files)

Scan OS Compatibility

Windows 10/8.1/7, Windows Server2008/2008 R2/2012/2012 R2/2016,
Mac OS X 10.9.5 or later

Authentication

iR2206: N/A
iR2006N & iR2206N: Department ID management (Max: 100 IDs)

Network

iR2206: N/A

iR2006N & iR2206N: Standard: IP/Mac Address Filtering, TLS Encrypted Communication, SNMP V3.0, IEEE 802.1X, IPv6, SMTP Authentication, POP Authentication before SMTP

Document

iR2206: N/A
iR2006N & iR2206N: Secure Print (Max: 100 IDs)

Paper Sizes

Cassette 1

A3,B4,A4R,A4,B5,B5R,A5R,India-LGL, FOOLSCAP

Cassette 2

iR2206: N/A
iR2006N & iR2206N: A3,B4,A4R,A4,A5,B5,B5R

Multi Purpose Tray

A3,B4,A4R,A4,B5,B5R,A5,A5R,India-LGL,
FOOLSCAP, Envelope (COM 10, Monarch, ISO-C5, DL)

Paper Input Capacity (Standard)

Cassette 1

250 sheets (80 gsm)

Multi Purpose Tray

80 sheets (80 gsm)

Paper Input Capacity (Optional)

Cassette 2^*

iR2206: N/A
iR2006N & iR2206N: 250 sheets (80 gsm)

Paper Specification

Cassette

Weight: 64 - 90 gsm
Type: Plain (64 to 90 gsm), Recycled (65 to 80gsm), Colour (64 to 80 gsm), Pre-punched (75 to 80 gsm)

Multi Purpose Tray

Weight: 60-128 gsm
Type: Plain (64 to 90 gsm), Heavy 1 (91 to 105 gsm), Heavy 2 (106 to 128 gsm), Recycled (65 to 80 gsm), Colour (64 to 80 gsm), Pre-punched (75 to 80 gsm), Bond (75 to 90 gsm), Transparency, Label, Envelope

Duplex Automatic Document Feeder - AY1^*

Type

iR2206: N/A
iR2006N & iR2206N: Automatic Document Feeder

Size of Originals

iR2206: N/A
iR2006N & iR2206N: A3, B4, A4, A4R, B5, B5R, A5, A5R, FOOLSCAP, India LGL

Paper Weight

iR2206: N/A
iR2006N & iR2206N:
When scanning continuously:
52 to 105 g/m²
When scanning a single original:
37 to 128 g/m²

Max. Number of Originals

iR2206: N/A
iR2006N & iR2206N: 50 sheets (A4, 80 gsm)

Scanning Speed (Simplex)

Copying (A4 in BW at 600 dpi)

iR2206: N/A
iR2006N: 20ipm
iR2206N: 22ipm

Scanning (A4 in BW 300 dpi)

iR2206: N/A
iR2006N & iR2206N: 23 ipm

Dimensions (W x D x H)

iR2206: N/A
iR2006N & iR2206N: 565 x 520.5 x 126 mm

Weight

iR2206: N/A
iR2006N & iR2206N: Approximately 7.0 kg

Cassette Feeding Module- AD1

Paper Sizes

iR2206: N/A
iR2006N & iR2206N: A3,B4,A4R,A4,A5,B5,B5R

Paper Capacity

iR2206: N/A
iR2006N & iR2206N: 250 sheets (80 gsm)

Power Source

iR2206: N/A
iR2006N & iR2206N: From main unit

Dimensions (W × D × H)

iR2206: N/A
iR2006N & iR2206N: 579 x 575 x 116 mm

Weight

iR2206: N/A
iR2006N & iR2206N: Approx. 5.75 kg
